- Housing: Aluminum
- EXIT sign plate: Tempered glass
- Hardware: Stainless steel
- Mounting Sling: Stainless steel
Series:
V Series
EX-W5
Select Variant
Contact
Follow
EX-W5
Series:
V Series
Features
- Suitable for wet location.
- Light weight and compact structure.
- Integrated junction box for driver with emergency backup.
- Ingress protection rating IP66.
- Low energy consumption.
- 3-hour emergency operation.
- Stainless-steel exposed fasteners with high corrosion resistance.
- Alternate exit legend and languages available.
- Sealed unit. BATTERY not replaceable. Replace entire exit sign unit when necessary.
Technical Specifications
General Specs
| Models | Electrical Ratings | Emgergency Time | Lifespan | Warranty | Ambient Temperature | Charge Time |
|---|---|---|---|---|---|---|
|
EX-5WVNRD180 (utilize red LEDs) EX-5WVNGD180 (utilize green LEDs) |
100-277VAC 60Hz 0.5A 5W |
3 hours | 50,000 hours | 5-year limited warranty | -20°C to +60°C | 24 hours |
Applications
Packing Information
Model
V Series
Net Weight
7.28 lbs
Packing Size
18.50x18.50x10.24inch
Quantity/Carton
2 Pcs
Gross Weight
15.43 lbs
Specifications Sheet
- Suitable for wet location.
- Light weight and compact structure.
- Integrated junction box for driver with emergency backup.
- Ingress protection rating IP66.
- Low energy consumption.
- 3-hour emergency operation.
- Stainless-steel exposed fasteners with high corrosion resistance.
- Alternate exit legend and languages available.
- Sealed unit. BATTERY not replaceable. Replace entire exit sign unit when necessary.
Dimensions
Specifications
Accessories
Technical Specifications
Part Number
Part Number
Electrical Specs
Input Voltage
100-277/200-480VAC
Power
Lighting Performance
Lumens
Correlated Color Temperature
Angles
